If you have spent any time on a construction site, you know that the foundation is what everything else stands on. Get it wrong and no amount of quality work above ground will save the structure.
Two of the most common shallow foundation types you will encounter are strip foundations and pad foundations. Students often confuse the two, and some site engineers use them without fully understanding why one is specified over the other.
This post breaks down exactly what each foundation is, how they differ structurally, and when each one is the right call. Whether you are reading a drawing for the first time or preparing for a site supervisor role, this is the knowledge you need.
Quick Answer: A strip foundation runs continuously under load-bearing walls to spread wall loads into the ground, while a pad foundation is an isolated block placed directly under columns to transfer concentrated point loads. The correct choice depends on the structural system of the building, the soil bearing capacity, and how loads are distributed.
What Is a Strip Foundation and When Is It Used?
A strip foundation is a continuous reinforced concrete footing that runs along the full length of a load-bearing wall. Its function is to spread the wall load over a larger ground area, reducing the contact pressure transferred into the soil below.
You will find strip foundations in masonry buildings, stone houses, and any structure where walls carry the primary loads to the ground. The strip width is calculated by dividing the total wall load (in kN/m) by the allowable bearing capacity of the soil (in kN/m²).
For example: if a wall carries 60 kN/m and the soil has an allowable bearing pressure of 100 kN/m², the strip must be at least 600 mm wide. This follows standard practice under BS 8110 and is confirmed by the structural engineer after a soil investigation.
In most East African construction contexts, strip foundation depths range from 600 mm to 1.2 m below natural ground level, depending on the soil profile and local site conditions.
What Is a Pad Foundation and Where Does It Fit?
A pad foundation is an isolated, square or rectangular block of reinforced concrete placed directly under a column. Unlike a strip, it does not run continuously. It sits alone and transfers a concentrated point load into the ground over a defined base area.
Pad foundations are standard in framed structures: buildings where the load is carried by columns rather than walls. A multi-storey office block, a warehouse, or a commercial building on a column-beam frame will typically use pad foundations at each column position.
The pad size is calculated from the column load and the allowable bearing capacity. If a column carries 500 kN and the soil can handle 150 kN/m², the pad needs a base area of at least 3.33 m² .. approximately 1.85 m x 1.85 m.
Pad foundations are designed to EC2 (Eurocode 2) or BS 8110, with two-way reinforcement to resist bending in both directions as the pad spreads the load outward from the column base.
Key Structural Differences: Strip vs Pad at a Glance
The simplest way to remember this: strip foundations follow the wall, pad foundations sit under the column. But the technical differences go deeper than shape.
| Feature | Strip Foundation | Pad Foundation |
|---|---|---|
| Load type | Distributed wall load | Concentrated column load |
| Structural system | Masonry or load-bearing walls | Framed column-beam structures |
| Shape | Continuous linear footing | Isolated square or rectangular block |
| Reinforcement | Nominal to moderate | Two-way reinforcement |
| Common use | Residential houses, boundary walls | Commercial and industrial buildings |
| Ground connection | Integral with load-bearing wall | Separate ground beams link pads |
The truth is, the choice between strip and pad is not a design preference. It follows directly from the structural system. Wall-bearing structures get strips. Column-bearing structures get pads.
How Soil Conditions Influence the Foundation Decision
Even when the structural system is clear, soil conditions can force adjustments. If the bearing capacity is very low .. below 50 kN/m² .. both strip and pad foundations may require unreasonably large dimensions to stay within safe bearing pressures.
In that case, the engineer may switch to a raft foundation, which spreads the entire building load across the whole floor area. A site investigation must be done before any foundation type is selected. Standard tests include the Standard Penetration Test (SPT) and plate load tests. The Kenya Standard KS 02-102 covers basic soil investigation procedures for local construction projects.
Honestly, most foundation failures in residential construction are not caused by poor design. They happen because no soil test was done and assumptions were made about the ground. That single decision leads to differential settlement, wall cracking, and in serious cases, structural collapse.
How to Read Foundation Types on a Structural Drawing
Strip foundations appear as continuous parallel lines following wall positions on the foundation plan. Each strip will have a cross-section detail showing width, depth, concrete grade, and reinforcement bar specification.
Pad foundations appear as isolated rectangles at column grid intersections on the plan. Each pad gets its own detail showing two-way reinforcement layout, column starter bars, cover specification, and overall dimensions. The plan will reference each pad by code .. P1, P2, P3 .. linked to a pad schedule in the drawing set.
In simple terms: if the foundation follows the wall line, it is a strip. If it sits alone at a column grid intersection, it is a pad.
Frequently Asked Questions
Q: Can you use pad foundations for a residential house?
Yes, but only if the house is designed as a column-and-beam frame rather than load-bearing masonry walls. Most low-cost residential construction in Kenya uses masonry walls, which means strip foundations are the correct specification for that building type.
Q: What is the minimum depth for a strip foundation?
The standard minimum is 600 mm below natural ground level, to get below the active zone where moisture and root activity affect soil behaviour. The structural engineer sets the final depth based on the soil investigation report and site conditions.
Q: What happens if the wrong foundation type is specified?
The wrong foundation creates uneven load distribution. This leads to differential settlement, cracking in walls and floor slabs, and in serious cases, structural instability. Always follow the engineer’s design drawings and raise any inconsistencies with the site supervisor before work starts.
